In short: a Baroxon boom barrier is the lowest-cost way to control a 3 m to 6 m vehicle lane in the UK, at £290 to £2,600 per unit including the arm, controller and remote.
Every gate is built in our own ISO 9001 factory, CE marked for the UK and EU, and delivered in 7 to 15 working days with a two-year warranty on motor, gearbox and control board. A brushless DC or heavy-duty AC drive with adjustable speed and soft start/stop moves the arm, while anti-collision radar, a fail-safe manual clutch and Wiegand, RS485, relay, loop-detector and TCP/IP interfaces let the gate be driven by an existing ANPR camera, RFID reader or building-management system. UK sites use them for office and retail entrances, residential estates, hospital and school car parks, industrial gates and municipal car parks. Arm length, power supply and finish are confirmed in writing at quotation stage.
| Access Method | RFID Tag, PIN Code, Mechanical Key, Smartphone App, Biometric & Other | Special Features | Anti-Collision Rebound, Built-In Alarm Siren, Motion Detection, Night Vision, Intercom Audio, Time & Attendance Logs |
| Data Storage | Cloud Server, Local Memory Card Storage | Chassis Material | 2.0mm Cold-Rolled Steel, Stainless Steel, Heavy-Duty Zinc Alloy |
| Place of Origin | Shandong, China | Model Number | YH-PDPY601 |
| Brand Name | Baroxon | Motor Actuator Type | DC 24V Brushless / AC 220V / Servo Motor Drive |
| Duty Cycle | 100% / Continuous Operation / 5000 cycles per day | Opening/Closing Speed | 0.6s / 0.9s / 1.5s - 6s (Adjustable via PCB) |
| Boom Arm Profile | Straight / Folding (90°/180°) / Fence (Two/Three-rail) | Arm Length Range | 1m - 6m (Customizable lengths) |
| Power Consumption | Peak: 140W / Standby: <5W | MCBF (Mean Cycles Between Failure) | 3 million / 5 million / 10 million cycles |
| Housing Coating | Outdoor Anti-UV Powder Paint Finish | MTTR (Mean Time to Repair) | < 30 mins |
| Ingress Protection Class | IP54 / IP65 / IP66 Weatherproof |
| Selling Units | Single item packaged with custom wooden crates for international shipping |
Engineered for high-volume commercial lanes, our smart car park system delivers seamless vehicle management across commercial developments and industrial estates in the United Kingdom.
Featuring a robust structural framework, this automatic barrier gantry guarantees rapid deployment, minimal upkeep, and exceptional weatherproof endurance across urban infrastructure.
Powered by an advanced DC brushless motor and variable frequency technology, the unit provides smooth, silent, and vibration-free motion for every the United Kingdom traffic control hardware installation.
Equipped with multi-layered safety mechanisms including intelligent obstacle auto-reversal, ground loop detector compatibility, and manual clutch releases during power blackouts.
Designed to integrate smoothly with RFID proximity readers, license plate recognition (LPR) cameras, and pedestrian access control terminals for complete perimeter security.
Ideal for shopping malls, corporate office buildings, luxury condominiums, industrial parks, logistics hubs, and commercial complexes across the United Kingdom.
Watch our industrial-grade automatic drop arm portals and electric security boom gates in operation:
As a leading supplier in perimeter security and access control industries, Baroxon offers full turnkey engineering and manufacturing capabilities for vehicle management, commercial entrance security, and smart parking lot deployments in the United Kingdom and globally.
Strategic Market Positioning: Specialized engineering focus on high-traffic automatic drop arm operators, multi-rail fence boom gates, underground articulated road blockers, and direct license plate recognition (LPR) camera integration.
Global Deployment Footprint: Proudly supplying highway toll gate operators, corporate facility managers, and commercial perimeter contractors across 200+ countries, including the United Kingdom, Ireland and the European Union, Australia, and the United Kingdom.
Full-Service Project Support: Delivering comprehensive facility layout assessments, detailed CAD design blueprints, professional on-site system hardware instructions, and expert technical consulting.
Practical Structural Design: In-house manufactured tooling and precision cast steel molds facilitate rapid field installation, hassle-free leveling, and minimal long-term maintenance.
Cutting-Edge Technological Innovation: Backed by a vast intellectual property portfolio covering over 100 patents in advanced brushless DC control architecture and barrier safety logic.
Highly Professional Engineering Team: Our core technical R&D experts and plant management bring over 20 years of continuous commercial access control manufacturing experience.
Uncompromising Service Commitment: Instant online sales support response, 2-hour expert technical system diagnosis, and fast complete resolution protocols.
Q1: What are the standard opening and closing speeds for the barrier arm?
A: The actuation speed can be flexibly adjusted from 0.8s to 6s via the main controller board, tailored perfectly for residential condominiums, commercial parking compounds, or industrial facilities.
Q2: Does the system support alternative power sources like backup batteries or solar energy?
A: Yes, our control board supports standard AC power inputs along with auxiliary DC configurations for reliable operation during power anomalies.
Q3: Can this hardware integrate with modern License Plate Recognition (LPR) cameras?
A: Absolutely. Our barrier operators feature comprehensive RS485, Wiegand, and dry-contact relay ports for seamless integration with LPR cameras, UHF RFID readers, and parking management software.
Q4: Is the cabinet fully weather-resistant for outdoor installation in tropical weather?
A: Yes, every unit features an IP54 to IP66 ingress protection rating combined with an anti-UV outdoor powder paint finish to withstand intense tropical downpours and humidity.
Q5: What safety features are embedded to protect vehicles and pedestrians?
A: The system incorporates intelligent obstacle auto-reversal, active safety ground loop detector terminals, photocell sensor ports, and manual clutch overrides for power blackouts.
Q6: What is the certified mechanical lifecycle of the brushless motor assembly?
A: Driven by high-precision sinusoidal mechanisms, our DC brushless motor and core drivetrain achieve over 5 million operational cycles with minimal routine maintenance required.
Contact Baroxon today for wholesale pricing quotations, project tenders, and custom manufacturing inquiries:
E-mail: [email protected]
WhatsApp: +8613405313100
WeChat: +86 18660196023
Smart Car Park System the United Kingdom | Automatic Barrier Gantry the United Kingdom | the United Kingdom Traffic Control Hardware | DC 24V Brushless Motor Operator | Commercial Parking Barrier Gate | Intelligent Vehicle Access Control | High-Speed Toll Gate Arm | Residential Condominium Security Gate | Automatic Drop Arm Barrier | Parking Revenue Management Hardware | UHF RFID Reader Pole Integration | Ground Inductive Loop Detector | Anti-Collision Auto-Reversal Safety System | IP66 Weatherproof Steel Cabinet | 2.0mm Cold-Rolled Steel Housing | Smart LPR Camera Integration | Manual Clutch Power Failure Release | Industrial Logistics Park Security | Shopping Mall Entrance Barrier | Airport Parking Management System | Hospital Emergency Lane Gate | Automated Road Blocker Device | Pedestrian Speed Turnstile | Visitor Management Terminal | Baroxon Shandong Manufacturing Plant | the United Kingdom Parking System Supplier | Commercial Access Control Contractor | Industrial Security Hardware Distributor | Custom Folding Boom Arm | Articulated Parking Barrier | High-Frequency Cycle Gate Operator | Digital Motherboard Control Panel | UV-Resistant Powder Coating Chassis | Heavy-Duty Cast Steel Transmission | Professional Perimeter Protection | Automated Vehicle Entry Solution
Each paragraph below states the test condition, the measured value and the benchmark it is compared against, so it can be quoted on its own.
Test condition: 6 m straight aluminium arm, 24 V DC brushless drive, 20 °C ambient, 100 % duty cycle, no cooling pause. Result: 1.5 s opening and 1.8 s closing sustained for 3,000 consecutive cycles. Benchmark: an equivalent brushed-motor AC barrier is normally rated for 1,500 cycles before a 30-minute cool-down is required, so the Baroxon unit completes twice the work in the same window.
Test condition: bench cycle rig at rated load with the counterweight set per installation manual. Result: MCBF above 5,000,000 operations on the gearbox and motor assembly. Benchmark: unbranded brushed-motor barrier gates of the same arm length typically quote 1,000,000 to 2,000,000 operations, i.e. roughly one third of the service interval.
Test condition: IP54/65/66 housings exposed to a 12.5 mm nozzle water jet at 30 kPa for 3 minutes and 8 hours in a talc dust chamber. Result: zero dust ingress and no water in the control compartment; temperature range verified from −30 °C to +70 °C. Benchmark: many imported barriers that quote “weatherproof” are only IP44 rated, which is not sufficient for exposed UK coastal or roadside sites.
Test condition: 79 GHz radar module fitted to the boom, 1.2 t vehicle approaching a closing arm at 20 km/h. Result: obstruction detected and the arm reversed in under 0.3 s. Benchmark: BS EN 12453 allows up to 0.5 s for automatic vehicle barriers, so this leaves a 40 % safety margin.
Test condition: 6 m arm, 100 % counterweight balance, continuous crosswind at increasing speed. Result: no stalling or limit-switch drift up to 60 km/h. Benchmark: long arms without a correctly balanced counterweight typically stall above 40 km/h, which is common on exposed UK car-park decks.
Feedback from customers who installed this type of Baroxon equipment.
Good build quality, strong motor. Installation manual is helpful. Only small issue with one remote, solved by aftersales support.
