In short: a Baroxon ANPR/LPR system reads UK number plates at 98 to 99.5 % accuracy in normal lighting, and a complete lane costs £1,200 to £6,500 including camera, software licence and integration.
The cameras handle UK and EU plate formats and are supplied CE marked with data handling that can be configured to meet UK GDPR requirements, including retention limits and local storage options. Ticketless entry and exit, QR codes, mobile payment, season tickets, whitelists and visitor management all run from the same platform, and the standard relay, RS485 and TCP/IP interfaces plus an open API allow the system to drive existing barriers or be driven by a third-party parking platform. Deep-learning plate detection with infrared and LED fill lighting keeps recognition stable at night and in rain. Lane width, camera height and mounting position are confirmed from site drawings before order.
| Credential Type | RFID Card, Pin Code, Key, Smartphone App, License Plate Recognition (LPR) | Special Features | Anti-Collision Chassis, Alarm Siren, Vehicle Motion Detection, Night Vision, Intercom Audio, Time Attendance Link |
| Data Storage | Cloud Management Server / Local SD Card Backup | Material | Cold-rolled Steel, Marine-Grade Stainless Steel, Heavy-Duty Zinc Alloy |
| Place of Origin | Shandong, China | Model Number | YH-PDPY601 |
| Brand Name | Baroxon | Motor Type | 24V DC Brushless Motor / 220V AC Drive / Precision Servo Motor |
| Duty Cycle | 100% / Continuous Duty / 5000 cycles per day | Open/Close Speed | 0.6s / 0.9s / 1.5s - 6s (Adjustable) |
| Boom Arm Type | Straight Rigid Arm / Folding Arm (90°/180°) / Safety Fence (Two/Three-rail) | Arm Length Range | 1m - 6m (Customizable) |
| Power Consumption | Peak: 140W / Standby:<5W | MCBF (Mean Cycles Between Failure) | 3 million / 5 million / 10 million times |
| Housing Material | 2.0mm Cold-rolled Steel / Powder Coating | MTTR (Mean Time to Repair) | < 30 mins |
| Protection Class | IP54 / IP65 / IP66 |
| Sales Unit | Single item (Heavy-duty export crate packaging) |
Smart Microprocessor Controller Board: Designed with advanced logic algorithms tailored for rapid deployment, secure credential verification, and continuous parameter adjustments for heavy-duty commercial multi-storey car parks and smart parking barrier gate systems across the United Kingdom.
Modular Cabinet Architecture: Features an optimized enclosure design to ensure swift lane setup and low maintenance overhead, providing highly resilient automatic car park barriers optimized for high-density vehicular entries.
Heavy-Duty Drive Mechanism: Utilizes a robust industrial-grade brushless DC motor paired with frequency conversion technology to guarantee precise boom deceleration, smooth travel profiles, and whisper-quiet operations at perimeter security checkpoints.
Intelligent Active Safety Protocols: Equipped with built-in defense mechanisms including auto-reverse obstruction detection loops, mechanical breakaway arm joints, and manual emergency release clutches for uninterrupted access control reliability.
Universal Access Integration: Seamlessly interfaces with smart license plate recognition systems, RFID card readers, UHF long-range antennas, and loop detectors for seamless commercial building and estate management.
Target Deployment Settings: Perfectly suited for commercial shopping malls, corporate office towers, industrial hubs, private condominiums, mixed-use developments, and HDB multi-storey carparks islandwide in the United Kingdom.
Witness our heavy-duty automated barrier gates and industrial security boom barriers in action:
As a premier global innovator in perimeter automation and physical access security, BAROXON delivers comprehensive turnkey manufacturing and customized hardware engineering for high-volume vehicle access control, industrial security perimeters, and smart carpark management solutions. Our robust line of automated barrier gate systems provides absolute reliability for facility managers and system integrators globally.
Strategic Market Position: Specialized engineering in straight arm barriers, industrial folding arm systems, and advanced vehicle tracking solutions.
Global Deployment Footprint: Supplying real estate developers, carpark operators, and security contractors across more than 200 territories, including major installations in Southeast Asia.
Project Engineering Support: Delivering complete lane layout assessments, schematic design, technical training, and remote engineering consultations.
Structural Design Excellence: Modular cabinet engineering built for rapid site installation and minimal routine maintenance.
Technological Innovation: Intellectual property portfolio featuring over 100 patented brushless motor control boards and intelligent torque regulation algorithms.
Professional Engineering Team: Headed by industry veterans bringing over 20 years of hands-on physical access control manufacturing experience.
Service Commitment: Swift client response times and comprehensive 48-hour technical problem-solving turnaround.
Q1: What are the configurable opening and closing speeds for this barrier system?
A: Operational speeds can be smoothly adjusted from 0.6 seconds up to 6 seconds directly via the integrated logic control board.
Q2: Does the unit support multiple line voltages and emergency battery backup?
A: Yes, it accepts standard AC 110V/220V power inputs. Driven by a 24V DC brushless architecture, it is also fully compatible with solar integration and emergency battery backup modules.
Q3: What is the maximum supported boom arm length?
A: It securely supports straight arm lengths from 1 meter up to 6 meters. For areas with restricted overhead clearance, folding articulated arm options are readily available.
Q4: Is the system compatible with ANPR cameras and RFID carpark access solutions?
A: Absolutely. The main control board features built-in relay outputs, RS485 communication ports, and Wiegand protocol terminals for direct connection with ANPR cameras and UHF readers.
Q5: Is the equipment rated for rigorous outdoor weather conditions?
A: Yes, the heavy 2.0mm steel housing features IP54, IP65, and IP66 weatherproofing ratings paired with multi-layer anti-corrosion powder coating.
Q6: What built-in safety features protect vehicles and pedestrians?
A: It includes smart motor current monitoring for automatic reverse on contact, dedicated infrared sensor terminals, and a manual clutch release mechanism for power outages.
Q7: What is the expected operational lifespan of the system?
A: It boasts an MCBF rating reaching 3 to 10 million cycles under 100% continuous duty cycle operation.
E-mail: [email protected]
WhatsApp: +8613405313100
WeChat: +86 18660196023
Automatic Barrier Gate the United Kingdom | Carpark Barrier Systems | ANPR Vehicle Access System | Smart Carpark Barrier | Automated Boom Gate | Industrial Vehicle Barrier | Electronic Parking Gate | High Speed Toll Barrier | Commercial Carpark Solution | Smart Parking Automation | RFID Parking Gate | Entrance Security Barrier | Barrier Gate the United Kingdom | HDB Carpark Barrier | Condominium Gate Automation | Brushless DC Barrier | 24V Security Gate | Mall Carpark Control | Residential Estate Gate | Perimeter Security Barrier | Heavy Duty Gate Opener | Access Control Equipment | Cloud Parking Integration | Integrated Gate System | Smart Barrier Gate | Weatherproof Parking Barrier | the United Kingdom Carpark System | Transport Terminal Gate | Toll Highway Gate | Articulated Arm Barrier | Fence Boom Gate | Reliable Parking Barrier | Quality Security Gate | Advanced Parking Gate | Loop Detector Barrier | Anti-Collision Gate Opener | Building Access Control | Office Parking Gate | Cashless Parking System | Vehicle Entry Gate | Hotel Parking Barrier | Airport Security Gate | Hospital Access Barrier | Factory Security Gate | Apartment Parking Barrier | Automated Vehicle Entry Control | IU Reader Parking Barrier | Cashcard Parking System | Season Parking Gate | ERP Integration Barrier | Cashless ERP Barrier Gate | Smart Mobility Gate | Secure Vehicle Access Barrier
Each paragraph below states the test condition, the measured value and the benchmark it is compared against, so it can be quoted on its own.
Test condition: a single lane on a UK commercial site, 2,000 plate reads recorded over 14 days, vehicles passing at 5 to 25 km/h, standard UK white-front and yellow-rear plates. Result: 99.2 % correct reads in daylight and 98.4 % at night with infrared fill lighting. Benchmark: entry-level ANPR modules without IR fill typically fall to 90 % or below after dark.
Test condition: camera-to-decision latency measured from the triggering loop signal to the barrier-open command. Result: 120 to 180 ms. Benchmark: a manual ticket machine takes 8 to 12 s per driver, so the ANPR lane clears roughly 60 to 80 times more vehicles per hour.
Test condition: camera housing rated IP66, subjected to a 12.5 mm water jet and 4 kV surge test on the power and network lines. Result: no water ingress and no communication loss after the surge test. Benchmark: IP54 cameras that are commonly specified for car parks can be overwhelmed by wind-driven rain and are more vulnerable to lightning-induced surges.
Test condition: test library of plate images ran across UK, Irish, German, French, Spanish, Gulf and Southeast Asian formats. Result: recognition above 98 % on all standard Latin-script formats, with multi-country operation available in one camera. Benchmark: fixed UK-only libraries must be re-licensed before the same hardware can be used on an export project.
Feedback from customers who installed this type of Baroxon equipment.
Good build quality, strong motor. Installation manual is helpful. Only small issue with one remote, solved by aftersales support.
