In short: a Baroxon RFID barrier lane reads vehicles from 6 to 12 m away, so fleets enter without stopping, at £780 to £4,200 for a complete set with gate, reader, controller and cards.
Long-range UHF readers cover the 6 to 12 m band for windscreen tags, while short-range readers handle 10 to 80 cm card and fob access at the same lane. Vehicle tags are IP68 rated and suitable for windscreen mounting in all UK weather, and multi-channel controllers let one controller manage several lanes from a single point. Wiegand, RS485 and relay outputs mean the lane can be integrated with most existing access-control, time-and-attendance and parking platforms, and the reader can be configured for anti-passback, timed occupancy and visitor whitelists. Reader power, tag population size and lane geometry are checked at quotation stage to confirm the read distance for your site.
| Access Modes | RFID Proximity Card, Handset Remotee, Mobile Application, UHF Long-Range Tag, ANPR Camera | Safety Features | Anti-Collision Rebound, LED Warning Ring, Inductive Loop Integration, Manual Release Key |
| Data Storage | Cloud Database, On-Board Local Memory | Enclosure Material | Cold-Rolled Steel, Stainless Steel, Heavy-Duty Alloy |
| Place of Origin | Shandong, China | Model Reference | YH-PDPY601 |
| Brand Identity | Baroxon | Drive Mechanism | DC 24V Brushless / AC 220V / Servo Motor Drive |
| Duty Cycle Rating | 100% / Continuous / 5000 cycles per day | Cycle Speed | 0.6s / 0.9s / 1.5s - 6s (Adjustable) |
| Arm Configuration | Straight / Folding (90°/180°) / Fence Arm | Arm Span Length | 1m - 6m (Adjustable) |
| Power Usage | Peak: 140W / Standby:<5W | MCBF Rating | 3 million / 5 million / 10 million cycles |
| Chassis Build | 2.0mm Cold-rolled Steel / Powder Coat | MTTR Benchmark | < 30 minutes |
| Ingress Protection | IP54 / IP65 / IP66 | ||
| Unit Package | Single industrial carton set | Box Dimensions | 104X37X33.5 cm |
| Gross Weight | 40.000 kg | ||
Microprocessor Control Architecture: Built with advanced logic boards supporting fast loop setups and smooth connectivity for automatic car park barrier systems in the United Kingdom, ensuring high throughput for commercial transit.
Modular Housing Design: Engineered to provide effortless site deployment and low servicing overheads. This robust configuration drives high-performance commercial vehicle boom gates designed to endure humid tropical climates and heavy workloads.
Inertia-Balanced Motor Drive: Utilizes low-noise brushless technology and digital frequency tracking to achieve precise braking, silent operational transit, and accurate arm alignment.
Comprehensive Safety Frameworks: Features physical breakaway couplings, pressure-sensitive auto-reversal modules, and manual release clutches for uninterrupted workflow during grid failures.
Ecosystem Interoperability: Seamlessly integrates with smart access readers, speed turnstiles, optical gates, loop sensors, and specialized smart RFID barrier systems.
Target Environments: Optimized for smart office towers, multi-storey complexes, industrial hubs, residential estates, transport terminals, and heavy-duty toll plazas.
As a trusted international supplier in perimeter security and asset governance, BAROXON delivers comprehensive manufacturing, precision automated machining, and high-volume distribution for automated lane management and smart parking ecosystems. Our maintenance-free commercial barriers ensure rapid vehicle flow and reliable weather protection under demanding conditions globally.
Strategic Market Footprint: Advanced engineering for heavy-duty commercial straight arm lane operators, multi-level fence gates, folding arms, and RFID barrier integrations.
Global Reach: Trusted by multinational infrastructure developers, municipal authorities, and security system integrators in over 200 countries.
Turnkey Project Support: Providing comprehensive site assessments, technical CAD blueprints, synchronization training, and direct factory consultation.
Efficient Structural Design: Precision-molded mechanical assemblies and modular electronics facilitate rapid site installation and minimal maintenance overheads.
Technological Innovation: Backed by an intellectual property portfolio featuring over 100 core patents covering digital brushless DC control systems.
Experienced R&D Team: Our engineering management possesses over 20 years of real-world expertise in perimeter turnstiles and gate hardware.
Service Commitment: Supported by prompt responses, expert technical diagnostics, and robust closed-loop resolution management.
Q1: What are the speed options and cycle limits for this barrier series?
A: This operator supports adjustable open/close speeds from 0.6s to 6s. Built with a 100% continuous duty rating, it supports heavy workloads up to 5000 cycles daily for high-speed lanes.
Q2: What motor configurations and power specifications are available?
A: Units can be configured with industrial 24V Brushless DC motors, AC 220V assemblies, or precision Servo Motors. Peak power draw is 140W under load, with standby drawing under 5W.
Q3: Which boom arm styles can be fitted to the housing?
A: The mechanism supports aerodynamic straight arms, 90° or 180° articulated folding arms for low-ceiling basements, and multi-rail fence configurations across 1m to 6m spans.
Q4: Can this gate interface with peripheral access control equipment?
A: Yes, the motherboard includes modern dry contact banks, integrating smoothly with ANPR cameras, proximity card readers, mobile entry apps, and inductive loops.
Q5: What weather protection and cabinet materials are provided?
A: Cabinets are fabricated from 2.0mm cold-rolled steel with multi-layer outdoor powder coatings, offering IP54, IP65, or IP66 ingress protection ratings for extreme environments.
Q6: What is the mechanical reliability and average repair turnaround time?
A: The drive assembly achieves an MCBF of 3 million, 5 million, or 10 million cycles depending on motor choice, with an MTTR of under 30 minutes for quick servicing.
Q7: What safety mechanisms handle obstacles and power outages?
A: The control board triggers immediate auto-reversal loops upon contact. Additionally, units include anti-collision breakaway adapters and mechanical manual clutches for power failure overrides.
Contact BAROXON today for wholesale quotes, project tenders, and custom manufacturing consultations:
E-mail: [email protected]
WhatsApp: +8613405313100
WeChat: +86 18660196023
Automatic Parking Barrier the United Kingdom | Commercial Parking Gate Mechanism | Automatic RFID Boom Barrier Gate | High Speed Toll Gate | 100% Duty Cycle Barrier | Brushless DC Barrier Motor | Industrial Security Boom Gate | IP66 Weatherproof Housing | Cold Rolled Steel Chassis | Folding Articulated Boom | Perimeter Fence Barrier | High MCBF Parking Barrier | Servo Motor Barrier Gate | Drop Arm Security Barrier | Commercial Traffic Security | Inductive Loop Detector | Smart Parking Access System | Residential Gate Access | Remotee Gate Opener | Vehicle Barrier System | Perimeter Security Gate | License Plate Recognition System | Car Park Entry Barrier | Heavy Duty Motorized Access | Toll Lane Security | RFID Gate Operator | Paid Parking Control | Driveway Access Control | DC Brushless Barrier Gate | Electric Security Boom | Barrier Gate Manufacturing | Smart Parking Gate | Traffic Safety Solutions | Automatic Road Barrier | Security Boom Gate | Vehicle Access Control | Checkpoint Access Control | Toll Lane Security | Automatic Entry Access | Motorized Access Gate | Roadside Barrier Gate | Entry Barrier System | Commercial Toll Barrier | Parking Arm | Smart Entry Barrier | Boom Operator | Logistics Barrier | Warehouse Parking Gate | Factory Access Gate | Airport Security Barrier | Train Station Gate | Hospital Gate System | University Parking Barrier | Stadium Gate | 220V Brushless Motor | Weather Resistant Barrier Box | Traffic Control Arm | Heavy Duty Parking System | Anti-Collision Loop Sensor | Access Card Turnstile | Pedestrian Gate | Supermarket Entrance Gate | Security Turnstile | Paid Parking Barrier | Electronic Lane Gate | Vehicle Control System | Driveway Boom Gate | Security Gate Operator | Motorized Road Barrier | Vehicle Detection Loop | Automatic Parking Cover | Entry Control System | Industrial Access Gate | Heavy Duty Barrier Gate | Fast Toll Barrier | Sinusoidal Parking Barrier | Durable Traffic Gate | Driveway Operator | Heavy Duty Housing | Automatic Barrier Arm | Commercial Vehicle Gate | Access Control Gate | Toll Booth Operator | Entry Point Barrier | Parking Gate Supplier | Custom Boom Barrier | Underground Garage Barrier | Low Clearance Folding Gate | High LED Boom Gate | Anti-Theft Barrier | Microcontroller Operator | Modular Security System | Low Noise Entry Gate | Variable Speed Arm Operator | Continuous Barrier Gate | Road Access Gate | Parking Lot Gate | Smart Barrier System | Commercial Perimeter Security | Driveway Entry Barrier | Factory Access Gate | Logistics Park Barrier | Port Security Barrier | Construction Site Gate | Government Facility Security | Campus Barrier | Checkpoint Barrier | High Performance Access Control | Automatic Vehicle Access | Commercial Parking Barrier | Industrial Barrier Operator | Exterior Boom Gate | Premium Gate Operator | Parking Entry System | Long Range Reader Barrier | Anti-Collision Gate | Efficient Brushless DC Operator | Access Control Equipment | Perimeter Protection | High Lifecycle Parking Barrier | Heavy Duty Toll System | Automatic Checkpoint Barrier | Motorized Road Operator | Entry Point Barrier | Commercial Access Operator | Industrial Vehicle Gate | Drop Arm Barrier | Lane Access System | Motorized Revenue Control | Turnstile Perimeter Control | Commercial Traffic System | Industrial Entry Control | Vehicle Barrier Gate | Automatic Traffic Control | Checkpoint Barrier | Shandong Security Gate | Low Clearance Barrier | Turnstile Traffic Control | Drop Arm Operator | Commercial Lane Security | Lane Barrier System | Barrier Gate Arm | Vehicle Checkpoint | Toll Plaza Gate | Electric Drop Arm Barrier | Automatic Road Boom Barrier | Remotee Gate Access | DC Brushless Barrier Motor | Industrial Entry Point Barrier | High Capacity Lot Operator | Road Access Boom Barrier | Electric Vehicle Operator | Commercial Drop Arm Operator | Smart Driveway Access Control | the United Kingdom Car Park Barrier | Smart Urban Mobility Access | ERP Toll Gate System | HDB Car Park Boom Gate | Condominium Security Barrier | Heathrow Airport Access Control | Tuas Industrial Boom Gate | Docklands Parking System | Smart Nation Access Hardware | Automated Vehicle Barrier SG | Expressway Toll Plaza Gate | Industrial Estate Gate Opener | Multi-Storey Car Park Barrier | Commercial Real Estate Security | Trusted Barrier Supplier the United Kingdom | Regional Traffic Control Gate | Secure Logistics Hub Barrier
Each paragraph below states the test condition, the measured value and the benchmark it is compared against, so it can be quoted on its own.
Test condition: UHF reader mounted 1.8 m high at 45°, vehicle approaching at 20 km/h, tag fitted to the windscreen behind a heated-glass strip. Result: consistent reads from 6 m, up to 12 m with the antenna aligned to the lane centre. Benchmark: proximity (125 kHz) card systems used for the same application need the driver to stop within 10 to 80 cm of the reader.
Test condition: 30 vehicles queued through a single lane with tags randomised in the cabin. Result: 100 % of tags read on first pass, no duplicate or dropped reads recorded. Benchmark: single-channel readers in mixed traffic commonly miss 3 % to 8 % of tags, which requires manual intervention at the gatehouse.
Test condition: IP68 vehicle tags soaked in water for 72 hours, then cycled between −30 °C and +70 °C for 50 thermal cycles. Result: no read failure and no housing deformation. Benchmark: IP65 tags, which are still widely sold for vehicle use, are not rated for immersion and commonly fail after a windscreen leak.
Test condition: reader operated in a lane that also carries Wi-Fi access points, 4G routers and a UHF handheld terminal. Result: no dropped reads and no cross-lane reads over a continuous 8-hour test. Benchmark: unshielded reader modules frequently trigger adjacent lanes at sites with dense wireless traffic, causing the wrong barrier to lift.
Feedback from customers who installed this type of Baroxon equipment.
Good build quality, strong motor. Installation manual is helpful. Only small issue with one remote, solved by aftersales support.
