In short: Baroxon pedestrian access control starts at £1,450 to £7,800 per lane and handles 25 to 60 people per minute depending on the barrier type, which is enough for a UK office lobby, stadium or transit concourse.
The range covers swing barriers, flap barriers, optical speed gates, tripod turnstiles and full-height turnstiles, and each lane can be fitted with RFID and IC cards, QR codes, fingerprint, palm vein or face recognition terminals. Wiegand, RS485 and TCP/IP interfaces with an open API link the lane to third-party access-control and attendance software, so staff, visitors and contractors can be managed in one system. Housings are stainless steel or powder-coated steel with IP54 or better protection for outdoor and semi-outdoor use, and every lane is supplied fail-safe open or fail-secure lock according to site policy, with a manual release fitted as standard so people are never trapped in a fire evacuation.
Premium Pedestrian Management Solution. The Baroxon Ba-YZS168 is a high-performance automatic swing gate system, specifically engineered to meet the stringent security standards of modern corporate offices, high-tech industrial plants, and public facilities. Built with robust 304 Stainless Steel and powered by a silent, high-endurance DC24V Brushless Motor, this unit guarantees a secure perimeter protection system for commercial hubs across the United Kingdom. This system fully supports seamless integration with biometric devices such as Face Recognition, Fingerprint scanners, and RFID Card reader modules for modern smart access control management.
| Protection Level | IP55 | Barrier Open/Close Time | 0.2 s - 2 s (Adjustable) |
| Barrier Motor | DC24V Brushless Motor (Heavy Duty) | Access Control Type | ESD System. Face Recognition. Fingerprint. IC Card. QR Code. RFID Card |
| Turnstile Function | Anti-Pinch. Anti-Tailgating. Collision Avoidance. Counting Function | Operation Direction | 2-Way (Bi-directional) |
| Communication Interface | TCP/IP. RS-232. RS485 (Network Ready) | Material | Stainless Steel 304 |
| Brand Name | Baroxon | Model Number | Ba-YZS168 |
| Dimensions | 1200*200*980mm | Working Environment | Outdoor (Shade) -25 ~ 70 |
1. Swing Turnstile: Features a barrier gate leaf that swings open/close, highly customizable to be widened for wheelchair accessibility and heavy pedestrian traffic.
2. Wing Gate Turnstile: Provides a standard lane width of 550-600mm, commonly utilized in public transport hubs like MRT stations, railway terminals, and airport lobbies.
3. Full Height Turnstile: Standing at 2.2 meters, this offers the maximum security coefficient, ideal for outdoor industrial plants or critical national infrastructure protection.
| Component | Detailed Specification |
| Product Name | Swing Turnstile Gate (Automatic Barrier System) |
| Material | 304 Stainless Steel (Anti-Rust) |
| Motor Type | Brushless Motor / Servo Motor Option |
| Channel Width | 600mm--900mm (Widened for Wheelchair Access) |
| Warranty | 2 Years Factory Warranty |
Corporate Offices: Installation of turnstile gates with proximity card readers and facial recognition for employee attendance and guest management.
Fitness Centers & Gyms: Members enter through face validation or RFID membership cards to prevent unauthorized entry to facilities.
Enterprise Canteens: Swing gate unit integrated with biometric scanners for meal entitlement tracking and staff authentication.
Residential Complexes: Full-height turnstiles installed at perimeters to significantly increase environment safety and site security.
 Card Reader Turnstile |  Swing Arm Barrier |  Wing Gate Turnstile |
 Biometric Turnstiles |  Full Height Security |  Tripod Turnstile Gate |
1. Who is the manufacturer of these security systems?
We are the professional manufacturer of Baroxon automatic turnstile systems, consistently delivering top-tier perimeter security solutions for the United Kingdom market.
2. What types of turnstiles do you produce?
We offer a complete ecosystem including swing turnstiles, flap barriers, high-speed wing gates, and tripod turnstiles for industrial and corporate sites.
3. How are quotations calculated for projects?
Pricing depends on the device type, lane width, and specific access control modules integrated, such as face recognition or ESD testing systems.
| Selling Units | Single item | Package Size | 120X20X100 cm |
| Gross Weight | 35.000 kg | Packaging Type | Sturdy export standard carton/wooden case |
Each paragraph below states the test condition, the measured value and the benchmark it is compared against, so it can be quoted on its own.
Test condition: single lane, card authentication, pedestrians walking at normal pace without luggage. Result: 25 to 30 people per minute on a tripod turnstile and up to 60 people per minute on an optical speed gate. Benchmark: a manually supervised swing gate with a guard checking passes normally clears 10 to 15 people per minute.
Test condition: 500 walk-through sequences, including deliberate attempts to follow closely behind an authorised user, tested with infrared sensor arrays in a 600 mm-wide lane. Result: 100 % of tailgate attempts detected and alarmed. Benchmark: turnstiles relying on a single beam typically miss 10 % to 20 % of close-follow attempts.
Test condition: obstacle placed in the closing path of a swing barrier, force measured at the wing edge. Result: peak impact force held below 45 N and the wing reversed immediately. Benchmark: EN 17352 sets the safe limit at 150 N, so this lane operates at roughly one third of the permitted force.
Test condition: continuous authentication cycles at rated speed with the lane in normal service use. Result: MCBF above 3,000,000 cycles; typical MTTR of 30 minutes because the reader, wing and mechanism are modular. Benchmark: enclosed proprietary lanes frequently need the whole wing assembly returned to the factory, giving typical repair times of several days.
