In short: a Baroxon ANPR/LPR system reads UK number plates at 98 to 99.5 % accuracy in normal lighting, and a complete lane costs £1,200 to £6,500 including camera, software licence and integration.
The cameras handle UK and EU plate formats and are supplied CE marked with data handling that can be configured to meet UK GDPR requirements, including retention limits and local storage options. Ticketless entry and exit, QR codes, mobile payment, season tickets, whitelists and visitor management all run from the same platform, and the standard relay, RS485 and TCP/IP interfaces plus an open API allow the system to drive existing barriers or be driven by a third-party parking platform. Deep-learning plate detection with infrared and LED fill lighting keeps recognition stable at night and in rain. Lane width, camera height and mounting position are confirmed from site drawings before order.
| Type | Card, Code, Key, Smartphone, UHF | Special Features | Anti-Theft, Built-In Siren, Motion Detection, Night Vision, Time & Attendance |
| Storage | Cloud, Memory Card | Material | Cold rolled steel, Stainless Steel, Zinc Alloy |
| Place of Origin | Shandong, China | Model Number | YH-PDPY601 |
| Brand Name | Baroxon | Motor Type | DC 24V Brushless / AC 220V / Servo Motor |
| Duty Cycle | 100% / Continuous / 5000 cycles per day | Opening/Closing Speed | 0.6s / 0.9s / 1.5s - 6s (Adjustable) |
| Boom Arm Type | Straight / Folding (90°/180°) / Fence (Two/Three-rail) | Arm Length Range | 1m - 6m (Customizable) |
| Power Consumption | Peak: 140W / Standby: <5W | MCBF | 3 million / 5 million / 10 million times |
| Housing Material | 2.0mm Cold-rolled Steel / Powder Coating | MTTR | < 30 mins |
| Protection Class | IP54 / IP65 / IP66 |
| Selling Units | Single industrial-grade unit |
Baroxon provides a premium intelligent access control ecosystem featuring a high-precision motherboard for seamless commercial management.
Our modular automatic boom barrier gate is designed for rapid field deployment and long-term maintenance-free operation.
We utilize advanced DC brushless motor and frequency conversion technology to ensure whisper-quiet, smooth operation at high-traffic facility entrances.
Safety is prioritized with our intelligent anti-collision and auto-rebound logic, fully compatible with our advanced LPR license plate recognition software.
As a premier supplier in the perimeter security and access control industry, Baroxon offers full turnkey engineering and manufacturing for vehicle access, corporate entry security, and intelligent parking lot deployment.
Q1: What are the variable speed configurations?
A: Standard cycles range from 0.8s to 6s, optimized for diverse traffic flow and tolling requirements.
Q2: Can the gate systems operate off-grid?
A: Yes, we provide low-voltage DC solutions specifically engineered for solar-powered or remote facility locations.
Q3: What is the maximum boom arm length available?
A: Our standard range is 3m to 6m, with full-custom manufacturing available for specialized project dimensions.
Q4: How does the system integrate with access software?
A: Our boards offer universal compatibility with LPR (License Plate Recognition), long-range UHF, RFID, and automated ticketing systems.
Q5: Are the units rated for extreme outdoor environments?
A: Yes, all units meet IP55/IP66 ratings and utilize UV-resistant industrial powder coating for long-term climate durability.
Q6: What safety protections are included?
A: Features include anti-crush sensors, auto-reverse logic, loop detector support, and manual clutch override.
Q7: What is the expected lifespan of the barrier gate?
A: Engineered for 5 million+ operational cycles, ensuring years of stable performance with minimal maintenance.
Contact Baroxon today for wholesale quotes, project tenders, and custom manufacturing needs: E-mail: [email protected] | WhatsApp: +8613405313100 | WeChat: +86 18660196023
Boom barrier and boom gate | High speed barrier gate | ALPR / LPR car plate system | Automatic RFID boom barrier | Turnstile gate barrier | Radar sensor | Parking lock | Barrier accessories
Each paragraph below states the test condition, the measured value and the benchmark it is compared against, so it can be quoted on its own.
Test condition: a single lane on a UK commercial site, 2,000 plate reads recorded over 14 days, vehicles passing at 5 to 25 km/h, standard UK white-front and yellow-rear plates. Result: 99.2 % correct reads in daylight and 98.4 % at night with infrared fill lighting. Benchmark: entry-level ANPR modules without IR fill typically fall to 90 % or below after dark.
Test condition: camera-to-decision latency measured from the triggering loop signal to the barrier-open command. Result: 120 to 180 ms. Benchmark: a manual ticket machine takes 8 to 12 s per driver, so the ANPR lane clears roughly 60 to 80 times more vehicles per hour.
Test condition: camera housing rated IP66, subjected to a 12.5 mm water jet and 4 kV surge test on the power and network lines. Result: no water ingress and no communication loss after the surge test. Benchmark: IP54 cameras that are commonly specified for car parks can be overwhelmed by wind-driven rain and are more vulnerable to lightning-induced surges.
Test condition: test library of plate images ran across UK, Irish, German, French, Spanish, Gulf and Southeast Asian formats. Result: recognition above 98 % on all standard Latin-script formats, with multi-country operation available in one camera. Benchmark: fixed UK-only libraries must be re-licensed before the same hardware can be used on an export project.
Feedback from customers who installed this type of Baroxon equipment.
We installed these boom barriers for our commercial parking lot. Stable operation, quiet movement. The technical support team gave clear installation guidance. Very satisfied, will reorder soon.
Great quality barrier gates. Works well under hot weather. Fast delivery and responsive after-sales service. Recommended for parking and compound access control.
